Optimize machining with 55°-65° cutter series engineered for material diversity:
- HRC-Specific Design: 0.8μm WC for impact resistance (HRC≤45), 0.4μm WC for precision (HRC≤55) — ideal for steel, stainless, cast iron, copper;
- Smart Coatings: TiAlN+TiSiN for wear protection, TiAlN+AlCrSiN for hardened materials;
- Full-Process Mastery: Achieve roughness to mirror finishes in one tool, boosting efficiency by 30%+!
Right cutter = Max productivity!
Maximize machining efficiency with our Standard Milling Cutter Series (55° to 65°), engineered to conquer diverse materials through customized WC substrates and advanced coatings. Each series delivers optimized performance for specific workpiece hardness (HRC), material types, and finishing stages:
Material-Specific Engineering
- Tough Materials (HRC≤45 Steel/Cast Iron):
55° Series leverage 0.8μm WC powder + TiAlN/TiSiN composite coating for supreme impact resistance in semi-roughing. Vertical PVD coating ensures uniform wear protection in harsh conditions.
- Precision Machining (HRC≤50 Alloys/Stainless Steel):
60° Series combines 0.4μm WC powder + 35° helix angle with TiAlN/AlCrSiN coating for flawless semi-finishing to finishing. Full CNC grinding + sandblasting guarantees ±0.01mm tolerance.
- Ultra-Hard Challenges (HRC≤55 Tool Steel/Stainless):
65° Series feature 40° helix angle + edge-prep design and TiAlSiN/TiAlN-AlCrSiN coatings – ideal for high-precision finishing.
Why Choose Right?
50% Longer Tool Life: Coatings like TiAlSiN reduce friction and thermal cracking.
Adaptive Machining: Match substrate grain size (0.4μm/0.8μm WC) to material hardness.
Cost Efficiency: The 60° Series offers affordable TiAlSiN-coated alternatives for HRC≤48 steel.
Specification
| Cutting Dia (D) | Cutting Len (L1) | Shank Dia (D) | Overall Len (L) | Flutes (F) |
| 1 | 3 | 4 | 50 | 4 |
| 1.5 | 4.5 | 4 | 50 | 4 |
| 2 | 6 | 4 | 50 | 4 |
| 2.5 | 7.5 | 4 | 50 | 4 |
| 3 | 9 | 4 | 50 | 4 |
| 3 | 9 | 3 | 50 | 4 |
| 3 | 12 | 3 | 75 | 4 |
| 3 | 15 | 3 | 100 | 4 |
| 3.5 | 10 | 4 | 50 | 4 |
| 4 | 10 | 4 | 50 | 4 |
| 4 | 16 | 4 | 75 | 4 |
| 4 | 20 | 4 | 100 | 4 |
| 5 | 13 | 6 | 50 | 4 |
| 5 | 13 | 5 | 50 | 4 |
| 5 | 20 | 5 | 75 | 4 |
| 5 | 25 | 5 | 100 | 4 |
| 6 | 15 | 6 | 50 | 4 |
| 6 | 24 | 6 | 75 | 4 |
| 6 | 30 | 6 | 100 | 4 |
| 8 | 20 | 8 | 60 | 4 |
| 8 | 30 | 8 | 75 | 4 |
| 8 | 35 | 8 | 100 | 4 |
| 10 | 25 | 10 | 75 | 4 |
| 10 | 40 | 10 | 100 | 4 |
| 12 | 30 | 12 | 75 | 4 |
| 12 | 45 | 12 | 100 | 4 |
| 14 | 45 | 14 | 100 | 4 |
| 16 | 45 | 16 | 100 | 4 |
| 18 | 45 | 18 | 100 | 4 |
| 20 | 45 | 20 | 100 | 4 |
| 6 | 45 | 6 | 150 | 4 |
| 8 | 50 | 8 | 150 | 4 |
| 10 | 50 | 10 | 150 | 4 |
| 12 | 60 | 12 | 150 | 4 |
| 14 | 70 | 14 | 150 | 4 |
| 16 | 75 | 16 | 150 | 4 |
| 18 | 75 | 18 | 150 | 4 |
| 20 | 75 | 20 | 150 | 4 |
| 2 | 6 | 2 | 50 | 4 |
| 25 | 45 | 25 | 100 | 4 |
